Cisco C9300L-48T-4X-A Switch
-
48 Gigabit Data Ports : Provides 48 ports of 10/100/1000 Ethernet for connecting a large fleet of workstations, servers, and high-speed data devices.
-
Fixed 4x 10G SFP+ Uplinks : Features integrated 10-Gigabit fiber ports, ensuring high-speed connectivity to the core and eliminating network bottlenecks.
-
Network Advantage L3 Feature Set : Unlocks elite software capabilities, including Full OSPF, BGP, EIGRP, and VRF-Lite for complex network segmentation.
-
StackWise-320 : Supports high-performance stacking with up to 320 Gbps of bandwidth, allowing for extreme scalability and unified management.
-
Advanced Security : Mapped with hardware-anchored AES-128 MACsec encryption, Secure Boot, and Cisco Trust Anchor for top-tier defense.
-
SD-Access & Cloud Ready : Designed for full automation via Cisco DNA Center and supports micro-segmentation for modern, intent-based networking.
7.770,00
1 in stock
1 in stock
Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.
Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.
Cisco C9300L-48T-4X-A Switch
The Cisco C9300L-48T-4X-A Switch represents a high-performance, fixed-uplink cornerstone within the Cisco Catalyst 9300L series. Specifically engineered as a foundational element for Software-Defined Access (SD-Access), this switch delivers enterprise-grade reliability and security for modern campus environments. Featuring 48 ports of dedicated data connectivity alongside high-speed 10G uplinks, it is the ideal solution for high-density access layer deployments where performance and scalability are paramount.
Key Features of the Cisco C9300L-48T-4X-A:
This switch is purpose-built to handle the rigors of a modern enterprise network, balancing raw throughput with sophisticated management capabilities.
- Fixed 10G Uplink Architecture: Equipped with four integrated 10GBase-X SFP+ uplink ports, this model ensures that your access layer never becomes a bottleneck when communicating with the network core.
- Advanced Layer 3 Routing: Provided with the Network Advantage license, the switch supports complex routing protocols including OSPF, EIGRP, and BGP, allowing for sophisticated network segmentation and traffic management.
- StackWise-320 Technology: Supports a stacking bandwidth of up to 320 Gbps, enabling up to eight switches to be managed as a single logical unit to simplify operations and increase resiliency.
- Superior Security Features: Features hardware-anchored secure boot and 256-bit AES encryption support, protecting the integrity of your hardware and the confidentiality of your data across the wire.
- High-Performance Throughput: With a switching capacity of 176 Gbps and a forwarding rate of 130.95 Mpps, the unit effortlessly handles the data demands of 48 concurrent gigabit connections.
Applications and Ideal Use Cases
The C9300L-48T-4X-A is uniquely positioned for environments that prioritize high-speed data throughput over integrated power delivery.
- Enterprise Data-Only Access Layers: Ideally suited for corporate headquarters or large office buildings where workstations, imaging equipment, and high-speed printers already have dedicated power sources, allowing for maximum port density without the overhead of PoE.
- High-Bandwidth Technical Workgroups: Perfectly fits research facilities or architectural firms moving massive datasets and CAD files, where the 10G SFP+ uplinks prevent congestion during peak local-to-cloud transfers.
- SD-Access and Automation Projects: As a Network Advantage model, it serves as a primary building block for IT departments transitioning to Cisco DNA Center for policy-based automation and micro-segmentation.
- Mission-Critical Branch Offices: Provides financial and healthcare institutions with headquarters-level security and performance in a cost-effective, fixed-configuration form factor that simplifies remote management.
Technical Specifications at a Glance
| Feature | Specification |
|---|---|
| Total 10/100/1000 Copper Ports | 48 Data ports |
| Uplink Configuration | 4 x 10G SFP+ Fixed Uplinks |
| Default Software License | Network Advantage |
| Stacking Bandwidth | 320 Gbps (StackWise-320) |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.95 Mpps |
| Chassis Dimensions | 1.73 x 17.5 x 16.1 Inches (1RU) |
| RAM / Flash Memory | 8 GB / 16 GB |
| MTBF | 380,080 hours |
| Brand |
Cisco |
|---|---|
| Built-in Devices |
RFID tag |
| Capacity |
IPv4 routes: 32000 ¦ IPv6 routes: 16000 ¦ Multicast scale: 8000 ¦ QoS scale entries: 5120 ¦ ACL scale entries: 5120 ¦ Routed ports: 416 ¦ VLANs supported: 4094 ¦ Switched virtual interfaces (SVIs): 1000 |
| Compliant Standards |
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 1 |
| Management Type |
Layer 3 Managed |
| Depth |
4.4 cm |
| Device Type |
Switch – 48 ports – L3 – stackable |
| Enclosure Type |
Rack-mountable |
| Encryption Algorithm |
128-bit AES, 256-bit AES |
| Features |
Quality of Service (QoS), Cisco StackWise Technology, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Remote Switch Port Analyzer (RSPAN), NetFlow, Energy Efficient Ethernet, Management Information Base (MIB), Class of S |
| Flash Memory |
16 GB |
| Height |
40.9 cm |
| Humidity Range Operating |
5 – 90% (non-condensing) |
| Humidity Range Storage |
5 – 90% (non-condensing) |
| Important product information |
The DNA licence is not included in the scope of delivery and must be ordered separately. Please contact your sales manager. |
| Installed Qty |
1 |
| Interfaces |
48 x 1000Base-T RJ-45 ¦ 4 x 10GBase-X SFP+ uplink ¦ 1 x management (LAN) RJ-45 ¦ 1 x console ¦ 1 x USB 2.0 |
| Jumbo Frame Support |
9198 bytes |
| MAC Address Table Size |
32000 entries |
| MTBF |
380,080 hours |
| Manufacturer |
Cisco Meraki |
| Max Storage Temperature |
70 °C |
| Max Supported Qty |
2 |
| Min Storage Temperature |
-40 °C |
| Performance |
Switching capacity with stacking: 496 Gbps ¦ Switching capacity: 176 Gbps ¦ Forwarding rate: 130.95 Mpps ¦ Forwarding rate with stacking: 369.05 Mpps |
| PoE Capability |
NoN PoE |
| Ports |
48 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink) |
| Port Count |
48 port |
| Power Device |
Internal power supply – hot-plug |
| Power Provided |
350 Watt |
| Power Redundancy |
Optional |
| RAM |
8 GB |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG |
| Routing Protocol |
OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Status Indicators |
Status |
| Subtype |
Gigabit Ethernet |
| Version |
original |
| Voltage Required |
AC 120/230 V (50 – 60 Hz) |
| Weight |
7 kg |
| Width |
44.5 cm |
